OSFP Product Family
Provides high bandwidth coherent interconnections in a client optics form factor
Octal Small Form-factor Pluggable (OSFP) solution that fits into high-density switch and router client ports for optical interconnect links
Powered by Greylock and Delphi DSP ASICs, and silicon photonic integrated circuits (PICs) for an optimized co-packaged design with 3D Siliconization
Supports an expansive list of interoperability modes including from Optical Internetworking Forum (OIF), OpenZR+ MSA, and OpenROADM MSA industry agreements
Supports DCI and service provider network applications
Simplify network
by plugging directly into routers and switches
Reduce
capital and operational expenditures
Increase performance
and reliability with lower power consumption
800G ZR+ OSFP Pluggable Coherent Optical Module
Metro/regional | service provider ROADM networks
Key Features
High-performance interoperable operation, leveraging the interop PCS mode from OpenROADM MSA, for reaches extending beyond 800ZR
Increased flexibility to support other host ethernet rates and multiple line rates
Powered by Delphi, Acacia’s 9th Generation DSP ASIC
Ideal for metro/regional Ethernet data center and service provider network interconnects
Specifications
Tx Power
>+1 dBm
Reach (amplified link)
4000 km+ (mode dependent)
Client Formats
100GbE/200GbE/400GbE/ 800GbE
Data Rate, Modulation
800G, Interop PCS
600G, PCS
400G, PCS
Wavelength
Tunable, 1528.58 nm to 1567.24 nm
Connector
LC
Case Temperature
-5° C to 75° C
Fiber
SMF
Interoperability
OADM interoperable PCS
800ZR OSFP Pluggable Coherent Optical Module
DCI
Key Features
Optimize 800 Gbps data center interconnect (DCI) edge links with reaches up to 120km using 16QAM transmission
Powered by Delphi, Acacia’s 9th Generation DSP ASIC
Ideal for amplified single-span data center interconnect applications
Specifications
Tx Power
>-11 dBm, -2 dBm
Reach (amplified link)
120 km
Client Formats
100GbE/200GbE/400GbE
Data Rate, Modulation
800G, 16QAM
600G, Interop PCS
400G, Interop QPSK/16QAM, PCS
Wavelength
Tunable, 1528.58 nm to 1567.24 nm
Connector
LC
Case Temperature
-5° C to 75° C
Fiber
SMF
Interoperability
OIF 800ZR, OpenROADM Interop PCS, OpenZR+ Interoperable 400G QPSK
400ZR OSFP Pluggable Coherent Optical Module
Edge DCI | Campus
Key Features
Optimize 400Gbps data center interconnect (DCI) edge links with reaches up to 120km using 16QAM transmission.
Ideal for amplified single span data center interconnect applications
Specifications
Tx Power
>-10 dBm
Reach (amplified link)
120 km
Client Formats
100GbE/200GbE/400GbE
Data Rate, Modulation
400G, 16QAM
Wavelength
Tunable, 1528.77 nm to 1547.72 nm
Connector
LC
Case Temperature
-5° C to 75° C
Fiber
SMF
Interoperability
OIF 400ZR
OpenZR+ OSFP Pluggable Coherent Optical Module
Metro Regional/DCI
Key Features
High-performance operation, leveraging elements of the carrier-centric OpenROADM MSA, for longer reaches than 400ZR
Increased flexibility to support other host ethernet rates andmultiple line rates.
Ideal for metro/regional Ethernet data center and service provider network interconnects
Specifications
Tx Power
>-10 dBm
Reach (amplified link)
4000 km+ (mode dependent)
Client Formats
100GbE/200GbE/400GbE
Data Rate, Modulation
400G, 16QAM
300G, 8QAM
200G, QPSK
100G, QPSK
Wavelength
Tunable, 1528.77 nm to 1547.72 nm
Connector
LC
Case Temperature
-5° C to 75° C
Fiber
SMF
Interoperability
OIF 400ZR, OpenZR+
3D Siliconization
Enhances signal integrity and performance via the reduction of electrical interconnects while improving efficiencies in cost, reliability, power and size.
Silicon Photonics
High-speed highly compact and scalable optical integrated circuits in silicon
Digital Signal Processing
Industry leading innovative low power and high optical performance DSP design
