QSFP-DD Product Family
Improve efficiency while reducing network costs
Quad Small Form-factor Pluggable Double Density (QSFP-DD) solution that fits into high-density switch and router client ports for optical interconnect links
Powered by Greylock and Delphi DSP ASICs, and silicon photonic integrated circuits (PICs) for an optimized co-packaged design with 3D Siliconization
Supports an expansive list of interoperability modes from Optical Internetworking Forum (OIF), OpenZR+ MSA, and OpenROADM MSA industry agreements
Covers data center interconnect (DCI) edge, metro/regional, long haul and ultra long haul networks, as well as service provider access network applications
Simplify network
by plugging directly into routers and switches
Reduce
both capital and operational expenditures
Increase performance
and reliability with lower power consumption
800G ZR+ QSFP-DD Pluggable Coherent Optical Module
Metro/regional | Service provider ROADM networks
Key Features
High-performance interoperable operation, leveraging the interop PCS mode from OpenROADM MSA, for reaches extending beyond 800ZR
Increased flexibility to support other host ethernet rates and multiple line rates
Powered by Delphi, Acacia’s 9th Generation DSP ASIC
Ideal for metro/regional Ethernet data center and service provider network interconnects
Specifications
Tx Power
>+1 dBm, with TOF
Reach (amplified link)
4000 km+ (mode dependent)
Client Formats
100GbE/200GbE/400GbE/ 800GbE
Data Rate, Modulation
800G, Interop PCS
600G, PCS
400G, PCS
Wavelength
Tunable, 1528.58 nm
to 1567.34 nm
Connector
LC
Case Temperature
-5° C to 75° C
Fiber
SMF
Interoperability
OpenROADM interoperable PCS
800ZR QSFP-DD Pluggable Coherent Optical Module
DCI
Key Features
Optimizes 800Gbps data center interconnect (DCI) edge links with reaches up to 120km using 16QAM transmission
Powered by Delphi, Acacia’s 9th Generation DSP ASIC
Ideal for amplified single-span data center interconnect applications
Specifications
Tx Power
-11 dBm, -2 dBm
Reach (amplified link)
120 km
Client Formats
100GbE/200GbE/400GbE
Data Rate, Modulation
800G, 16QAM
600G, Interop PCS
400G, Interop QPSK/16QAM, PCS
Wavelength
Tunable, 1528.58 nm
to 1567.34 nm
Connector
LC
Case Temperature
-5° C to 75° C
Fiber
SMF
Interoperability
OIF 800ZR, OpenROADM Interop PCS, OpenZR+ interoperable 400G QPSK
400G Ultra Long Haul QSFP-DD Pluggable Coherent Optical Module
Long Haul/Ultra Long Haul
Key Features
High optical transmit output power greater than +1dBm
Increased flexibility to support other host ethernet rates and multiple line rates
Powered by Delphi, Acacia’s 9th Generation DSP ASIC
Ideal for long haul and ultra long haul service provider ROADM network applications
Specifications
Tx Power
>+1 dBm, with TOF
Reach (amplified link)
4000 km+ (mode dependent)
Client Formats
100GbE/200GbE/400GbE
Data Rate, Modulation
400G/200G/100G, QPSK, 16QAM, PCS
Wavelength
Tunable, 1528.58 nm
to 1567.34 nm
Connector
LC
Case Temperature
-5° C to 75° C
Fiber
SMF
Interoperability
OpenROADM 400G QPSK, OpenZR+ interoperable 400G/200G/100G
Bright 400ZR+ QSFP-DD Pluggable Coherent Optical Module
Metro/regional | Service provider ROADM networks
Key Features
High optical transmitter output power greater than +1dBm for 400G transmission over ROADM line systems including those with colorless multiplexing architectures.
Increased flexibility to support other host ethernet rates and multiple line rates.
High-performance operation, OTUc and OTU4 client support
Ideal for metro/regional and service provider ROADM network applications
Specifications
Tx Power
>+1 dBm, with TOF
Reach (amplified link)
4000 km+ (mode dependent)
Client Formats
100GbE/200GbE/400GbE
OTUCn/OTU4
Data Rate, Modulation
400G, 16QAM
300G, 8QAM
200G, QPSK
100G, QPSK
Wavelength
Tunable, 1528.58 nm
to 1567.34 nm
Connector
LC
Case Temperature
-5° C to 75° C
Fiber
SMF
Interoperability
OIF 400ZR, OpenZR+,
OpenROADM
400ZR QSFP-DD Pluggable Coherent Optical Module
DCI
Key Features
Optimize 400Gbps data center interconnect (DCI) edge links with reaches up to 120km using 16QAM transmission.
Ideal for amplified single span data center interconnect applications
Specifications
Tx Power
>-10 dBm
Reach (amplified link)
120 km
Client Formats
100GbE/200GbE/400GbE
Data Rate, Modulation
400G, 16QAM
Wavelength
Tunable, 1528.58 nm to 1567.34 nm
Connector
LC
Case Temperature
-5° C to 75° C
Fiber
SMF
Interoperability
OIF 400ZR
OpenZR+ QSFP-DD Pluggable Coherent Optical Module
Metro/regional Ethernet data center | Service provider network interconnects
Key Features
High-performance operation, leveraging elements of the carrier-centric OpenROADM MSA, for longer reaches than 400ZR
Increased flexibility to support other host ethernet rates and multiple line rates.
Ideal for metro/regional Ethernet data center and service provider network interconnects
Specifications
Tx Power
>-10 dBm
Reach (amplified link)
4000 km+ (mode dependent)
Client Formats
100GbE/200GbE/400GbE
Data Rate, Modulation
400G, 16QAM
300G, 8QAM
200G, QPSK
100G, QPSK
Wavelength
Tunable
1528.58 nm to 1567.34 nm
Connector
LC
Case Temperature
-5° C to 75° C
Fiber
SMF
Interoperability
OIF 400ZR, OpenZR+
400G ER1 QSFP-DD Pluggable Coherent Optical Module
Point-to-point Enterprise | Access | DCI Edge
Key Features
Optimizes 400Gbps short links with reaches up to 45km using 16QAM transmission
Ideal for unamplified point-to-point links
Specifications
Reach (amplified link)
45 km
Link budget
>12.5 dB
Client Formats
100GbE/400GbE
Data Rate, Modulation
400G, 16QAM
Wavelength
Fixed, C-band
Connector
LC
Case Temperature
-5° C to 75° C
Fiber
SMF
Interoperability
OIF 400ZR application code 0x02, OpenZR+ protocol support
100G DWDM Access QSFP-DD Pluggable Coherent Optical Module
Edge, Access | Cable/fiber deep | 5G wireless x-haul
Key Features
Meet growing bandwidth demands in edge and access networks.
Provide a scalable traffic aggregation solution, as well as an upgrade path to migrate from existing 10G WDM networks to higher-performing 100G DWDM coherent links
3D Siliconization
Enhances signal integrity and performance via the reduction of electrical interconnects while improving efficiencies in cost, reliability, power and size.
Silicon Photonics
High-speed highly compact and scalable optical integrated circuits in silicon
Digital Signal Processing
Industry leading innovative low power and high optical performance DSP design
